AD-361p 0-10V 0-500ppm Digital display Trace PPM Moisture
Easy user calibration procedure
Low maintenance and long life sensor expectancy
– Sample connections：KF40 Port
– Lower detection limit：0.05 Vppm
– Measuring range：0 … 500 Vppm
– Resolution：0.1 Vppm
– Value display：no display
– Analogue output：4 … 20 mA (optional 0 … 10 V)
– connection socket：5 – pin. (Binder Serie 680)
– Measuring cable：app.. 2 m, open cable ends
– Body material ：stainless steel
– Sensor material：Noble metal on glass or ceramic carrier
– leakage rate < 5×10 -8 mbar x l / s-1
– Gas flow：konstant, ca. 20 Nl/h
– Measuring gas temperature ：+5 … +65 °C
– Measuring gas pressure：max. 200 mbarg
– Measuring accuracy：+/- 5% of value, mind. 0,4 Vppm
– Response time in a moisture event < 1 sec
– Returne time, T50 < 2 min.
– warm up time：highly dependent on the measuring conditions
– Reproducibility：by 10,0 Vppm +/- 5%
– Dimensions：58mm X 80mm X 190mm
– Weight：0.7 kg
